- Specifications
QK-ALMCH-MC
Features
· Product Item: QK-ALMCH-MC01
· Materials: Aluminium A356-T6, Aluminium 6061-T6, Stainless Steel SS304/316, Brass C26000
· Surface Treatment: Black Anodic Oxidation, Passivation
· Sealing Material: NBR , EPDM, FPM, PTFE
· Casting Method: Casting, Forging, CNC Machining
. Standard: JIS B 2001, JIS B 2002, JIS B 8371, JIS B9911
. Pressure: 1.50 MPA - 2.50 MPA
The main function of the Machine Coupling Female Blank Cap is to prevent impurities from entering the system. When the connector is not connected or in use, the exposed end of the female connector is easily invaded by dust, moisture, moisture, and other impurities. The female blank cover serves as a barrier to block the entry of these pollutants and keep the system clean. By effectively sealing the female connector, it helps to maintain the overall efficiency and reliability of the Fluid power system.
SIZE | D | d | L | IMPA |
1.5''(40A) | 78 | 38 | 125 | 330855 |
2.0''(50A) | 94 | 51 | 161 | 330856 |
2.5''(65A) | 114 | 63.5 | 195 | 330857 |
3.0''(75A) | 125 | 76 | 232 | 330858 |
4.0'' | 167 | 101 | 291 |
