Forging Aluminum PN20/ Class 150/150# Flange Victaulic Grooved Large Diameter Lay-flat Hose Coupling

Main Description

• Qruck’s Flange Victaulic Grooved Large Diameter Lay-Flat Hose Coupling consists of grooved hose shanks, segmented bindings, sleeves, rubber seals and connection clips with screws & Nuts. The flange structure creates a reliable connection between hose and different equipments. And the follow both types of Flange LDHC Grooved Hose Coupling are available to our production.



  - Forging Aluminum PN20/ Class 150 Flange Victaulic Grooved Large Diameter Lay-flat Hose Coupling

  - Stainless Steel SS304/SS316 Victaulic Grooved Large Diameter Lay-flat Hose Coupling with 150# flange end

•

• Qruck’s Flange Grooved LDHC Grooved Hose Coupling represents a specialized integration of Victaulic's world-renowned groove mechanical piping technology with large-diameter, collapsible lay-flat hoses. Designed for high-flow fluid transfer in demanding environments, these couplings provide a fast, secure, and reliable method for connecting hoses used in dewatering, mining, irrigation, and emergency response. Rather than using traditional band clamps or bolted flanges, this system utilizes a housing that engages with a groove on the hose stem fitting, creating a rigid, leak-tight seal that can be assembled or disassembled in minutes with standard tools.



  - The flange with bolts & nuts offer reliable and quick connection between hose and different equipments (Pump, Valve, Water Divider and others).

  - The Vic grooved design for shank and binding can hold the hose tightly in place during liquid transfer and connection. The bindings bite into the hose to secure it.

  - The high performance rubber seals offer good and long sealing during liquid transfer and connection.

  - The segmented binding offers quick on-site installation and connection between equipments and hoses.

  - The high strength Aluminum with forging process offer reliable working pressure.

  - 12.9 high grade screws with nuts offers safety and tight locking work.

  - The hard anodizing offers high wear resistance and long durability.
